Product Details
Size (inch): | 3.5 | Resolution: | 320*480 |
Brightness (cd/m²): | 300 Nit | Interface: | MCU 8/16bit RGB 18bit SPI 3/4wire |
Driver Ic | ILI9488 |
|
Payment & Shipping Terms
Minimum Order Quantity | 1 piece | Price | Please contact us for latest price |
Packaging Details | FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm | Delivery Time | 1-7 working days |
Payment Terms | T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram | Supply Ability | 40,000 PCS per day |
New published TFT Touch Screen for commercial and industrial use. Our TFT LCD has a 3.5 inch diagonally. The resolution of our tft lcd is 320 * 480. The normal brightness is 300 nits under the test of laboratory.
Parameter:
Model | P035C018-TP |
Screen Size | 3.5 inch |
Number of Pixel | 320RGB(H)x480(V) |
Display area | 48.96(H)x73.44(V)mm |
Pixel pitch | 0.153(H)x0.153(V)mm |
Pin | 50 pin |
Outline Dimension | 54.48x84.71x2.25mm |
Pixel arrangement | RGB Vertical Stripe |
Display mode | Normally White |
Viewing Direction(eye) | 12 0'CLOCK |
Display Color | 262k |
Luminance(cd/m2) | 300 nit |
Contrast Ratio | 500:1 |
Interface | MCU 8/16bit RGB 18bit SPI 3/4wire |
Back-light | LED Side-light type |
Drive IC | ILI9488 |
Operation Temperature | -20~70℃ |
Storage Temperature | -30~80℃ |
The Interface of this LCD is MCU 16bit. We can also customize other types of interfaces and FPCs for you. The ILI9488 driver IC provides on-chip storage and power system. If your products need to work under a temperature from -20°C to 70°C, then it can meet your needs.
