Product Details
Size (inch): | 3.5 Inch 320*240 | Brightness (cd/m²): | 350 Nit |
Interface: | 3Line_SPI_24BIT_RGB | Driver IC: | ST7272A |
Viewing Direction(eye): | ALL | Contrast Ratio: | 1200:1 |
Display Area: | 70.08(H) X 52.56(V) Mm |
|
Payment & Shipping Terms
Minimum Order Quantity | 1 piece | Price | Please contact us for latest price |
Packaging Details | FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm | Delivery Time | 1-7 working days |
Payment Terms | T/T,L/C,Credit card,PayPal,D/A,D/P,Western Union,MoneyGram | Supply Ability | 40,000 PCS per day |
Parameter:
| Model | P035B084-IPS |
| Screen Size | 3.5 inch |
| Number of Pixel | 320RGB(H)x240(V) |
| Display area | 70.08(H)x52.56(V)mm |
| Pixel pitch | 0.073(H)x0.219(V)mm |
| Pins | 54 pins |
| Outline Dimension | 76.84x63.84x3.20mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 16.7M |
| Luminance(cd/m2) | 350 nit |
| Contrast Ratio | 1200:1 |
| Interface | 3Line_SPI_24BIT_RGB |
| Back-light | LED Side-light type |
| Drive IC | ST7272A |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
